Hardware / A personal project

Vehicle telemetry with Raspberry Pi.

A car’s OBD-II port, an ELM327 Bluetooth adapter, and a Python dashboard on a Raspberry Pi.

Originally built in 2019 as a hobby project, this console reads vehicle data over Bluetooth and displays speed and engine RPM on the Pi. Here are the original demo, system diagram and dashboard screenshots.

The original demo.

A recording of the Raspberry Pi vehicle telemetry console, using an ELM327 adapter to connect to the car’s OBD-II port.

If the player is unavailable, watch the original video on YouTube ↗.

From the car to the console.

The local Raspberry Pi dashboard is the implemented part of this project. The original diagram also records a proposed 4G connection to Kafka for telemetry streaming and further analysis.

Original architecture showing a vehicle connected to a Raspberry Pi over Bluetooth or CAN Bus, with a planned 4G link to Kafka for telemetry and anomaly analysis
Original project architecture, including planned extensions.Open full-size diagram ↗

Implemented

  • Read OBD-II data through an ELM327 Bluetooth adapter.
  • Run a custom Python instrument dashboard on the Raspberry Pi.
  • Display vehicle speed and engine RPM.

Planned extensions

  • Send telemetry over a 4G connection to Kafka.
  • Use Spark ML for anomaly detection.
  • Explore fault prediction with machine learning.

A closer look at the dashboard.

Retained screenshots from the original console. Open any image to inspect it at its original size.
